Sony ICF-CD2000 - Manual (Page 4)

Precautions
• Operate the unit on the power sources
specified in "Specifications,"
• The nameplate indicating voltage, etc. is
located at the bottom.
• Disconnect the AC power adaptor cord by
grasping the plug. Never pull it by the cord.
• Do not leave the unit in a location near a heat
source such as a radiator or airduct, or in a
place subject to direct sunlight, excessive dust,
mechanical vibration, or sh(x:k.
• Allow adequate air circulation to prevent
internal heat build-up. Do not place the unit on
a surface (a rug, a blaiUcet, etc.) or near
materials (a curtain) which might block the
ventilation holes.
• Should any liquid or solid object fall into the
unit, unplug (or remove batteries from) the
unit and have it checked by a qualified
persormel before operating it further.
• When the casing becomes soiled, clean it with a
soft cloth dampened with a mild detergent
solution. Never use abrasive cleansers or
chemical solvents, as they may mar the casing.
• The unit is not discoimected from the AC
power source (mains) as long as it is connected
to the wall outlet, even if the unit itself has
been turned off.
If you have any question, please consult your
nearest Sony dealer.
Notes on Headphones
Road safety
Do not use headphones while driving, cycling, or
operating any motorized vehicle. It may create a
traffic hazard and is illegal in many areas. It can
also be potentially dangerous to play your
headphones at high volume while walking,
especially at pedestrian crossings. You should
exercise extreme caution or discontinue use in
potentially hazardous situations.
Preventing hearing damage
Avoid using headphones at high volume.
Hearing experts advise against continuous, loud
and extended play. If you experience a ringing in
your ears, reduce volume or discontinue use.
Caring for others
Keep the volume at a moderate level. This will
allow you to hear outside sounds and to be
considerate to people around you.
Specifications
CD player section
System
Compact disc digital audio system
Laser diode properties
Material: GaAlAs
Wavelength: 780 nm
Emission duration: Continuous
Laser output: Less than 44.6 pW
(This output is the value measured at a
distance of about 200 mm from the objective
lens surface on the optical pick-up block with
7mm aperture.)
Frequency response
20-20,000 Hz is dB
Wow and flutter
Below measurable limit
Radio section
Frequency range
Band Frequency Channel step
FM 87,5-108 MHz 0.1 MHz
AM 530-1,710 kHz 10 kHz
FM 87.5-108 MHz 0.05 MHz
AM 531-1,710 kHz 9 kHz
General
Time display
12-hour system
Speaker
Full range: 4 cm (T/^ inches), 8 ohms (2)
Output
0 (headphones) jack (stereo minijack, 3.5 mm
dia.)
Power output
200mW + 200mW (at 10% harmonic
distortion)
Power requirements
Main unit:
• 6V DC, four size AA (LR6) alkaline
batteries
• DC IN 6V jack accepts supplied AC power
adaptor for use with 120 V AC, 60 Hz
Backup for Clock: 3V DC, one CR 2025
lithium battery
External power source
DCIN6V
Dimensions
Approx. 166.5 X 34 X 173 mm (w/h/d)
(Approx. 6^/j X X 6 inches)
inch projecting parts and controls
Mass
Approx. 660 g (1 lb 7 oz) ind. batteries
