Sony CCD-TRV66 - Manual (Page 13)

step 2 Inserting a cassette
When you want to record in the Hi8 system, use Hi8 video cassette HIEO.
(1) Slide EJECT in the direction of the arrow while pressing the small blue button.
The cassette compartment automatically lifts up and opens.
(2) Insert a cassette with its window facing out and the tab on the cassette up.
(3) Close the cassette compartment by pressing the "PUSH" mark on the cassette
compartment. The cassette compartment automatically goes down.
To eject a cassette
Slide EJECT in the direction of the arrow while pressing the small blue button.
Note
Do not press the cassette compartment down. Doing so may cause malfunction.
To prevent accidental erasure
Slide the write-protect tab on the cassette to expose the red mark.
13
