Operation Manual - JUICE BOX™ Settings
For Race Use Only
The Juice Box™ is legal ONLY for closed course race vehicles. The Juice Box™ is not
applicable, nor inteded for use on EMISSIONS CONTROLLED street, highway or off-road
vehicles. The Juice Box™ is not applicable, nor inteded for use on aircraft.
Mode 1 - green
Mode 4 - green/blue Mode 5 - Yellow/blue Mode 6 - red/blue
Mode 2 - Yellow Mode 3 - red
Pre-set Settings: R6/R6S baseline settings with stock air filter and TBR slip-on system. (G=0.5, Y=2, R=3, GB=N/A, YB=4, RB=3)
For additional settings please visit our website at www.twobros.com.
Two Brothers Racing
Juice Box™ - Fuel Controller
2003-05 Yamaha R6/2006-07 Yamaha R6S Installation & Operation Manual
Part # 008-22, 008-22S
