ITBR001-229 2008-10 CanAm Spyder - 6
Fi
gu
re
J
Fi
gur
e K
Fi
gu
re
L
ground
wire
unplug
harness
13 Attach the ground wire from the Juice Box Pro to the rear cylinder head on the left
side as shown in Figure J.
Remove the stock bolt and insert the bolt through the eyelet of the Juice Box Pro
ground wire and reinstall the bolt into the head.
14 Reinstall the air box.
15 Using the supplied zip ties, secure the Juice Box Pro harness along with the stock
harness in the original location.
16 Unplug the stock wiring harness from the O2 sensor as shown in Figure L.
This connection is located near the battery box. The inner tail section will need to be
removed to access this connection.
17 Route the Juice Box Pro 4-pin connectors to the location shown in Figure L.
18 Attach the 4-pin connectors from the Juice Box Pro to the stock wiring harness and
O2 sensor.
19 Reinstall the body work.
