Two Brothers Racing Can-Am Spyder Spyder RS - Manual (Page 3)

ITBR001-229 2008-10 CanAm Spyder - 3
Fi
gu
re
A
Fi
gur
e B
Fi
gu
re
C
remove covers
air box cover
remove bolts
remove bolt
The ignition must be turned OFF before installation.
1 Remove the cosmetic covers on both the right and left sides as shown in Figure A.
2 Release the clips around the edge of the air box cover and remove the cover as
shown in Figure B.
3 Remove the six bolts securing the air box base and remove the base as shown in
Figure C.
Only four bolts are visible in Figure C.
4 Cut the three zip ties on the left side of the air box securing the wiring harness.
5 Pull the air box base out the right side.
This will allow access to the injector connectors.
