Two Brothers Racing S1 Pro - Manual

Installation Instructions
1. Remove and identify all parts from packaging.
2. Locate the “T” on the hoop insert to determine the top.
3. Stand the left and right sides up.
4. Inster stand hoop into center of side supports with “T”
facing up.
5. Use supplied 8x25mm socket head flat bolts and
tighten to 15 ft-lbs.
*Do not force bolts, if you need to, loosen pre-installed
bolts to align threaded backing plate correctly. Loosely
install all bolts before final tightening.
6. After lifting the stand a couple of times re-tighten
all screws.
TBR
S1Pro Rear-Stand
Part # 007-007-G, 007-007-K, 007-007-GR, 007-007-R, 007-007-B
Parts List
Qty. Description
1
Left Side Stand Assembly
1 Right Side Stand Assembly
1 Stainless Steel Hoop
1 HARDWARE KIT
4 8x25mm Socket Head Flat Bolt
1 5mm Long Handle Ball End Hex Key
