Two Brothers Racing Triumph Tiger 1050 - Manual (Page 2)

005-2590407V 005-2590406V 005-2590408V
Qty. Description Part Number
1 Muffler Canister 005-259-206V
1 Muffler Canister Clamp 005-2C
1 Slip-On Tube 005-25904S
1 HARDWARE KIT 005-259-3
1 X-Ring 005-7-2-2
1 8x40mm Flange Bolt 005-FB840
1 8mm Flange Nut 005-FN8
1 18mm Aluminum Spacer 005-S-18
1 Muffler Mounting Bracket 005-69B
1 5mm Long Handle Ball End Hex Key 005-9-18610
1 T20 Torx Screw Hex Key 005-9-15820
4 6x14mm Socket Head Cap Screw 005-SH614
4 M6 Split Lock Washer 005-WL6
1 TBR Sticker Kit 015-10212
Qty. Description Part Number
1 Muffler Canister 005-259-207V
1 Muffler Canister Clamp 005-2C1
1 Slip-On Tube 005-25904S
1 HARDWARE KIT 005-259-3
1 X-Ring 005-7-2-2
1 8x40mm Flange Bolt 005-FB840
1 8mm Flange Nut 005-FN8
1 18mm Aluminum Spacer 005-S-18
1 Muffler Mounting Bracket 005-69B
1 5mm Long Handle Ball End Hex Key 005-9-18610
1 T20 Torx Screw Hex Key 005-9-15820
4 6x14mm Socket Head Cap Screw 005-SH614
4 M6 Split Lock Washer 005-WL6
1 TBR Sticker Kit 015-10212
Qty. Description Part Number
1 Muffler Canister 005-259-208V
1 Muffler Canister Clamp 005-2C2
1 Slip-On Tube 005-25904S
1 HARDWARE KIT 005-259-3
1 X-Ring 005-7-2-2
1 8x40mm Flange Bolt 005-FB840
1 8mm Flange Nut 005-FN8
1 18mm Aluminum Spacer 005-S-18
1 Muffler Mounting Bracket 005-69B
1 5mm Long Handle Ball End Hex Key 005-9-18610
1 T20 Torx Screw Hex Key 005-9-15820
4 6x14mm Socket Head Cap Screw 005-SH614
4 M6 Split Lock Washer 005-WL6
1 TBR Sticker Kit 015-10212
V.A.L.E.
V a r i a b l e a x i s l o c k i n g e x h a u s t
TM
2007-09 Triumph
Tiger 1050
V.A.L.E. Slip-on Exhaust System
Part # 005-2590406V / 005-2590407V / 005-2590408V
Care & Cleaning / Warranty Information
Care & Cleaning
Keep system free of dirt and moisture. Store in a cool, dry place. For cleaning use a mild spray cleaner.
Always apply cleaner or polish with a soft, clean cloth.
Stainless Header System: Polished stainless steel pipes will turn a light golden hue after a few heat
cycles, this is a normal characteristic of high quality stainless steel.
Carbon Fiber Mufflers: Always make sure the fiberglass packing inside is in good condition and not
burned out, as exhaust heat inside an empty canister will deteriorate the Carbon Fiber sleeve. TBR
sells repack kits (TBR part # 005-10038) that include new rivets and repack material as well as a drill
bit (#30), making it easy to do yourself. Also, NEVER dyno test your bike with carbon fiber mufflers
installed - the intense heat and lack of cooling air can quickly cause the CF material to burn. Two
Brothers Racing does not provide a warranty for burned carbon fiber.
Aluminum Mufflers: Use an aluminum or mag wheel polish such as Mother’s to restore the bright
finish to factory spec.
two brothers racing products are intended for closed course competition purposes only, and therefore are sold “as
is” without warranty. two brothers racing specifically disclaims any warranties of merchantability or fitness for a
particular purpose and disclaims all responsibility for consequential and incidental damages or any other losses aris-
ing from the use of these products or parts.
