Two Brothers Racing Kawasaki Z750 User Manual
V.a.l.e, Kawasaki z750

1.
Make sure the bike is completely cool before starting
the installation. Make sure the bike is secure on the
sidestand or ideally a service lift.
2.
Remove OEM muffler assembly by removing
the two mounting bolts on the muffler assembly
and removing the exhaust valve cables from the
servo motor which is located on the left side.
* If you remove te servo wheel you must hold it in place
with a suitable tool before loosening the retaining bolt
to be sure not to damage the servo motor. The servo
motor must remain plugged into the harness to keep
the engine light from turning on.
3.
Attach the TBR slip-on tube to the TBR muffler using the
4 6x14mm socket head cap screws and lock washers
provided. Leave loose for now.
4.
Slide rubber lined muffler clamp over muffler assembly
and install on motorcycle using the supplied bolt/spacer
and nut with OEM washer. The spacer will go between
the muffler clamp and OEM mounting bracket.
V.A.L.E.
V a r i a b l e a x i s l o c k i n g e x h a u s t
TM
Parts List
IMPORTANT - PLEASE READ CAREFULLY
We recommend that this performance part be installed by a qualified
motorcycle technician. If you have any doubts as to your ability to
install this performance part, please consult with your local motorcycle
dealer. Read all instructions first before starting installation. Make sure
the motorcycle and exhaust system are completely cool before starting
the installation. Also, make sure the bike is secure on a centerstand
or ideally a service lift during installation. Be sure to save all stock
components for possible use later.
Installation Instructions
5.
Install OEM mid-pipe bracket hardware to secure mid
section to motorcycle.
6.
Check muffler alignment and tighten the 4 X-Ring bolts
in a cross pattern.
7.
Tighten joint clamp.
8.
Re-install any removed parts.
9.
Check for clearance and make adjustments if needed.
10. Before you run the bike, clean off all fingerprints and
dirt, as any oily residue will etch the metal and become
somewhat permanent when the system gets hot. Run
the bike and enjoy. It is normal for some white smoke to
appear the first time you start the bike. This is packing/
manufacturing oil from inside the pipe burning off. After
50 to 100 miles, recheck all fasteners for tightness.
2007-09
Kawasaki Z750
Slip-On Exhaust System with M-2 Canister
Part # 005-2640406V / 005-2640407V / 005-2640408V
Qty. Description
Part Number
1
Muffler Canister M-2
Varies
1
Slip-On Tube
005-26404S
1
Muffler Clamp
Varies
1
HARDWARE KIT
005-264-3
2
V.A.L.E.™ X-Lite Ring half
005-7-2-3
4
6x14mm Socket Head Cap Screw
005-SH614
4
Split Lock Washer
005-WL6
1
10x60mm Socket Head Cap Screw
005-SH1060
1
10mm Flange Nut
005-FN10
1
11.5mm Aluminum Spacer
005-S-11-10
1
5mm Long Handle Ball end hex key
005-9-18610
1
T20 Torx Screw key
005-9-15820
1
TBR sticker Kit
015-10212
