Two Brothers Racing Kawasaki Ninja 650R - Manual (Page 2)

Installation Instructions
V.A.L.E.
V A R I A B L E A X I S L O C K I N G E X H A U S T
TM
12. Tighten mounting hardware and clamp on canister then tighten the barrel
clamp.
13. Double check all of your work and tighten all hardware.
14. Re-install the lower fairing and side cover.
15. Before you run the bike, clean off all fingerprints and dirt, as any oily
residue will etch the metal and become somewhat permanent when the
system gets hot. Run the bike and enjoy. It is normal for some white smoke
to appear the first time you start the bike. This is packing/manufacturing oil
from inside the pipe burning off. Check for gaps or leaks. If you find a leak,
a little high temperature silicon sealant should fix it. After 50 to 100 miles,
recheck all fasteners for tightness.
Care & Cleaning
Care & Cleaning
Keep system free of dirt and moisture. Store in a cool, dry place. Make sure vehicle is
completely cool before maintenance.
Stainless Header System: Polished stainless steel pipes will turn a light golden hue
after a few heat cycles, this is a normal characteristic of high quality stainless steel.
Clean using a mild water based spray cleaner. Always apply cleaner or polish with a soft,
clean cloth.
Titanium Header System: Polished titanium pipes will experience color shift ranging
from deep blue/purple through amber after a few heat cycles. This is a normal
characteristic of high quality titanium. Clean using a mild water based spray cleaner.
Always apply cleaner or polish with a soft, clean cloth.
Polished Aluminum Canisters: Use an aluminum or mag wheel polish to restore the
bright finish to factory spec.
Brushed Aluminum Canisters: Clean using a mild water based spray cleaner. Always
apply cleaner or polish with a soft, clean cloth.
Carbon Fiber Canisters: Clean using a mild water based spray cleaner. Always apply
cleaner or polish with a soft, clean cloth. Always make sure the fiberglass packing inside
is in good condition and not burned out, as exhaust heat inside an empty canister will
deteriorate the carbon fiber sleeve.
TBR sells repack kits (Road - #005-10038, Offroad - #005-10038MX) that include
everything you need to easily do it yourself.
Titanium Mufflers: For cleaning use a mild water based spray cleaner. Always apply
cleaner or polish with a soft, clean cloth. Always make sure the fiberglass packing inside
is in good condition and not burned out, as exhaust heat inside an empty canister will
deteriorate the carbon fiber sleeve.
TBR sells repack kits (Road - #005-10038, Offroad - #005-10038MX) that include
everything you need to easily do it yourself.
Repack all road canisters every 3,000 miles. Part #005-10038
Repack all offroad canisters after every 10 hours of use. Part #005-10038MX
NEVER dyno test your bike with carbon fiber or titanium canisters installed - the
intense heat and lack of cooling air can quickly burn through the canister material. Two
Brothers Racing does not provide a warranty for burned canisters.
Warranty
Two Brothers Racing products are intended for closed course competition purposes only, and therefore are sold “as is”
without warranty. Two Brothers Racing specifically disclaims any warranties of merchantability or fitness for a particular
purpose and disclaims all responsibility for consequential and incidental damages or any other losses arising from the use
of these products or parts.
Kawasaki
NINJA 650R (06-10)/ VERSYS (08-10)/ ER-6N (09-10)
Slip-on V.A.L.E.™ Exhaust System with M-2 Canister
Part # 005-1420406V / 005-1420407V / 005-1420408V
Qty. Description Part Number
1 M-2 Muffler Canister 005-142-207V
1 Stainless Steel Slip-On Tube 005-14201S
1 Muffler Clamp 005-2C1-113
1 HARDWARE KIT 005-142-3
1 X-Lite™ V.A.L.E.™ Retaining Ring 005-7-2-3KIT
1 P1 Power Tip™ (Installed) 005-P1
1 8x16mm Flange Bolt 005-FB816
1 8x35mm Flange Bolt 005-FB835
2 8mm Flange Nut 005-FN8
1 Support Bracket 005-142-19
1 Barrel Clamp 005-27-59MSH
1 TBR Sticker Kit 015-10212
