Two Brothers Racing Honda CRF450X User Manual
V.a.l.e, Crf 450x

V.A.L.E.
V a r i a b l e a x i s l o c k i n g e x h a u s t
TM
IMPORTANT - PLEASE READ CAREFULLY
Warranty
two brothers racing products are intended for closed course competition purposes only, and therefore are sold “as is”
without warranty. two brothers racing specifically disclaims any warranties of merchantability or fitness for a particular
purpose and disclaims all responsibility for consequential and incidental damages or any other losses arising from the use
of these products or parts.
We recommend that this performance part be installed by a qualified
motorcycle technician. If you have any doubts as to your ability to install this
performance part, please consult with your local motorcycle dealer. Read all
instructions first before starting installation. Make sure the motorcycle and
exhaust system are completely cool before starting the installation. Also,
make sure the bike is secure on a centerstand or ideally a service lift during
installation. Be sure to save all stock components for possible use later.
Installation Instructions
1. Make sure the bike is completely cool before starting the
installation. Make sure the bike is secure on a centerstand
or ideally a service lift.
2. Remove right side rear plastic.
3. Remove lower mounting bolt.
4. Remove upper muffler mounting bolt and muffler assembly.
5. Use the 4 (four) 6x14mm socket head cap screws and lock
washers to loosely attach the X-Lite™ ring to muffler inlet.
Qty.
Description
Part Number
1
CRF450X Muffler Canister M-7 Aluminum
005-133-206M
1
CRF450X SS Slip-on Tube
005-13301S
1
HARDWARE KIT
005-133-3
1
X-Ring Kit
005-7-2-3KIT
1
8x25mm Flange Bolt
005-FB825
1
TBR Script Logo Yellow Decal 4”
015-10212
1
Spark Arrestor (Installed)
005-106S
6. Slip S-bend tube of V.A.L.E. muffler assembly into head pipe.
7. Attach muffler mounting bracket to mounting tab on subframe
using supplied 8x25mm bolt. Leave loose for now.
8. Using OEM bolt, secure muffler assembly mid-pipe bolt.
Tighten securely.
9. Securely tighten the 4 (four) 6x14mm hex head bolts of the
V.A.L.E. assembly.
2005-09 Honda
CRF 450X
V.A.L.E.™ Slip-on Exhaust System with M-7 Aluminum Canister
Part # 005-1330406V
Parts List
Continued on page 2
