Two Brothers Racing Honda CBR1000RR User Manual
Cbr1000rr, Honda

Parts List
IMPORTANT - PLEASE READ CAREFULLY
We recommend that this performance part be installed by a qualified motorcycle technician. If
you have any doubts as to your ability to install this performance part, please consult with your
local motorcycle dealer. Read all instructions first before starting installation. Make sure the
motorcycle and exhaust system are completely cool before starting the installation. Also, make
sure the bike is secure on a centerstand or ideally a service lift during installation. Be sure to
save all stock components for possible use later.
Installation Instructions
5.
Remove left and right upper fairings, and lower fairing.
6.
Remove Radiator bolts, leave radiator in place. This will help
create space to remove OEM headers and installation of TBR
headers.
7.
Remove OEM lower mounting hardware, this will not
be reused.
1.
Make sure the bike is completely cool before starting the
installation. Make sure the bike is secure on a centerstand or
ideally a service lift.
2.
Remove the seat cowl, and the seat.
3.
Mark the location of servo. Disconnect Servo Butterfly valve
cable and re-route cable as shown (It will be removed later
with exhaust). Return servo to its original location or engine
light may be tripped.
4.
Remove the muffler mounting bolts & muffler assembly.
Qty.
Description
Part Number
1
M-2 Muffler Canister
Varies
1
Slip-On Tube Assembly
005-20601S
1
Canister Clamp
Varies
1
Header Kit
005-20601H
1
Adaptor Kit
005-92-22KIT
1
Custom Mounting Bracket
005-206B
1
X-Ring Kit
005-7-2-3KIT
1
Barrel Clamp
005-27-63MSH
1
8x20mm Socket Head Cap Screw
005-SHF820
1
8mm Aluminum Washer
005-WA8
1
8mm Flange Nut
005-FN8
1
Permatex Ultra Black Gasket Maker
031-P22072
1
TBR Sticker Kit
015-10212
*NOTE: If
removal
of fairings
becomes
complicated
please refer to
owners manual
for correct
procedure.
Honda
CBR1000RR
V.A.L.E.™ Full Exhaust System with M-2 Canister
Part # 005-2060106V / 005-2060107V / 005-2060108V
