7-4 C OMPUTER U PGRADES M Y P RESARIO —G ETTING S TARTED
The upper front panel door
was designed with finger holes
to make opening the door
easy.
The drive data cable has a
color pull tab to help you
identify the cable.
The drive rails snap on and off
the drive(s). Save the drive
rails that came with your
computer. They will be used
on your new drive(s).
Tip
Tip
Tip
5. Grasp under the bottom of the
upper front panel door, lift up,
and gently remove from the
hooks.
6. Press both sides of the drive
rails and pull the empty drive
bay from the front of the
computer.
7. Remove rails from empty drive
bay and attach them to the new
drive by connecting them to the
industry standard holes located
on each side.
8. Slide drive into the empty
drive bay.
9. Connect the data cable to
the new drive.
10. Connect the audio and
power cables to the new
drive.
