3-28 User Interface
Writer: Fran Spragens Project: User Interface Comments:
File Name:3324_3.doc Last Saved On:3/16/99 3:05 PM
Port Statistics Screen Descriptions continued
Field Description
Broadcasts Transmitted Total number of broadcast frames transmitted on the port.
Broadcasts Received Total number of broadcast frames received on the port.
Multicasts Transmitted Total number of multicast frames transmitted on the port.
Multicasts Received Total number of multicast frames received on the port.
Bytes Transmitted Total number of bytes transmitted on the port.
Bytes Received Total number of bytes received on the port.
Pause Frames Transmitted Total number of flow control pause frames transmitted on the port (not used)
Pause Frames Received Total number of flow control pause frames received on the port.
Collisions Total number of collisions detected on the port.
Late Collisions Total number of late collisions detected on the port.
CRC/Alignment Errors Total number of frames received on the port which had either a CRC or an
alignment error.
Undersized Frames Total number of frames received on the port which were undersized.
Oversized Frames Total number of frames received on the port which were oversized.
Fragments Total number of frames received on the port which were fragments.
Jabbers Total number of frames received on the port which were jabbers.
64 Byte Frames Total number of frames received on the port which were 64 bytes in length.
65 to 127 Byte Frames Total number of frames received on the port which were from 65 to 127 bytes
in length.
128 to 255 Byte Frames Total number of frames received on the port which were from 128 to 255 bytes
in length.
256 to 511 Byte Frames Total number of frames received on the port which were from 256 to 511 bytes
in length.
512 to 1023 Byte Frames Total number of frames received on the port which were from 512 to 1023 bytes in
length.
1024 to 1518 Byte Frames Total number of frames received on the port which were from 1024 to 1518 bytes
in length.
Refresh Refreshes port statistics.
Clear Clears (or sets to zero) port statistics.
