2-11
Compaq SW3322/SW3323/SW3324 Dual-Speed Switch User Guide
Writer: Fran Spragens Project: Installation Comments:
File Name:3324_2.doc Last Saved On:3/16/99 11:34 AM
Table 2-3 outlines specifications for gigabit ethernet cable.
Table 2-3
Gigabit Ethernet Fiber Specifications
Interface Type
Fiber Type
Fiber Diameter
(microns)
Modal Bandwidth
(MHz*km)
Maximum
Length (m)
1000Base-SX
Multimode
62.5
160
220
Multimode
62.5
200
275
Multimode
50
400
500
Multimode
50
500
550
1000Base-LX
Multimode
62.5
500
550
Multimode
50
400
550
Multimode
50
500
550
Single-mode
10
N/A
5000
1000Base-SX/LX Ports
The 1000Base-SX/LX ports use identical SC fiber connectors and multimode
62.5/125
µ
m fiber. The Gigabit Ethernet ports support IEEE 802.3z Gigabit
Ethernet through the use of modular Gigabit Interface Converters (GBICs).
Supported media includes multimode fiber and single mode fiber.
