3-13
Compaq SW3322/SW3323/SW3324 Dual-Speed Switch User Guide
Writer: Fran Spragens Project: User Interface Comments:
File Name:3324_3.doc Last Saved On:3/16/99 3:05 PM
Figure 3-9 shows the Spanning Tree Port Configuration Menu and Table 3-8
describes the menu. .
Figure 3-9 Spanning Tree Port Configuration Menu Selections
Table 3-8
Spanning Tree Port Configuration Descriptions
Field Description
Port ID A unique identifier for a port on the bridge (switch).
Port Name The administrative name assigned to the port.
Path Cost The contribution of the path through this port, when it is the root port, to the total path
cost from this bridge to the root bridge. 10 for 100Mbps ports, 100 for 10Mbps ports.
Port Priority The relative priority of the port on the bridge.
Port State The current Spanning Tree state of the port on the bridge, either disabled, listening,
learning, forwarding, or blocking.
Next Page Displays the next page of the table.
Previous Page Displays the previous page of the table.
First Page Displays the first page (top) of the table.
Last Page Displays the last page of the table.
Select Port Allows you to enter a port number to view and modify port parameters in the Spanning
Tree Port #n Configuration Menu.
SPANNING TREE PORT CONFIGURATION Access Control: READ/WRITE
PORT ID PORT NAME PATH COST PORT PRIORITY PORT STATE
------------------------------------------------------------------------
1 10 128 FORWARDING
2 10 128 FORWARDING
3 10 128 FORWARDING
4 10 128 FORWARDING
5 10 128 FORWARDING
6 10 128 FORWARDING
7 10 128 FORWARDING
8 10 128 FORWARDING
9 10 128 FORWARDING
10 10 128 FORWARDING
n. Next Page p. Previous Page f. First Page l. Last Page
a. Select Port x. Previous Menu
Enter Selection:
