Switch Summary Screen
The Switch Summary Screen allows you to display sum total statistics for all
ports of the switch. You can also clear or refresh the statistics. Select s from the
Switch Statistics Screen to view the Switch Summary screen. Figure 3-20
shows the Switch Summary Screen and Table 3-19 describes the screen.
Figure 3-20 Switch Summary Screen
Table 3-19
Switch Summary Screen Descriptions
Field Description
Frames Transmitted Total number of frames transmitted out all ports.
Frames Received Total number of frames received on all ports.
Frames Forwarded Total number of frames forwarded through the switch.
Frames Filtered Total number of frames filtered on all ports.
Frames Dropped Total number of frames dropped by the switch due to lack of resources.
Frames Errored Total number of errored frames received from all ports.
Refresh Refreshes switch summary statistics.
Clear Clears (or sets to zero) switch summary statistics.
SWITCH SUMMARY Access Control:
READ/WRITE
Frames Transmitted 0
Frames Received 0
Frames Forwarded 0
Frames Filtered 0
Frames Dropped 0
Frames Errored 0
r. Refresh c. Clear x. Previous Menu
Enter Selection:
