11. Gently push down near the middle of the back plastic computer base so that the two system-board securing clips clear

their slots, and then pull out the system board.

1 system-board securing clips (2)

Installing the System Board

1. Follow all of the steps in "

" in reverse order.

NOTICE:

Before turning on the computer, replace all screws and ensure that no stray screws remain inside the

computer. Failure to do so may result in damage to the computer.

2. Turn on the computer.

NOTE:

After replacing the system board, enter the computer Service Tag into the BIOS of the replacement system

board.

3. Insert the floppy disk or CD that accompanied the replacement system board into the appropriate drive. Follow the

instructions that appear on the screen.
