Specifications
Display
Type (TrueLife) 15.4-inch CCFL WXGA Anti-Glare
15.4-inch CCFL WXGA+ with TrueLife
15.4-inch CCFL WUXGA with TrueLife
15.4-inch WXGA+WLED with TrueLife
Dimensions:
Height 207 mm (8.14 in)
Width 331.2 mm (13.03 in)
Diagonal 391.2 mm (15.4 in)
Maximum resolutions:
WXGA AG 1280 x 800 at 262 K colors
WXGA+ with TrueLife 1440 x 900 at 262 K colors
WUXGA+with TrueLife 1600 x 1200 at 262 K colors
Refresh rate 60 Hz
Operating angle 0 ° (closed) to 140°
Viewing angles:
Horizontal ±40° (WXGA AG)
±55° (WXGA+ with TrueLife)
±55° (WUXGA+ with TrueLife)
Vertical +15°/–30° (WXGA AG)
±45° (WXGA+ with TrueLife)
±45° (WUXGA+ with TrueLife)
Pixel pitch:
WXGA AG 0.258 mm
WXGA+ with TrueLife 0.2304 mm
WUXGA+with TrueLife 0.1725 mm
Controls brightness can be controlled through keyboard
shortcuts (see Dell Technology Guide for more
information.)
