Page 40

Peripheral Configuration Submenu
IDE Configuration Submenu
Option
Function
USB Controller
Sets the USB controller to either Enabled (default) or Disabled.
Legacy USB Support Set to Disabled if legacy USB support is not desired. Enabled (default) allows support for legacy USB.
Integrated Audio
Sets the integrated audio controller to either Enabled (default) or Disabled.
Serial Port
Sets the integrated serial port setting to Auto, (default) 2E8/IRQ3, 3E8/IRQ4, 2F8/IRQ3, 3F8/IRQ4, or Disabled.
Parallel Port
Sets the integrated parallel port setting to Auto, (default) 3BC/IRQ7, 278/IRQ5, 378/IRQ7, or Disabled.
Parallel Port Mode
Sets the integrated parallel port mode to Bi-directional (default), Output Only, ECP, or EPP.
ECP Mode Use DMA If the Parallel Port Mode option is set to ECP, this setting selects the ECP DMA mode. The options are 3 (default) and 1.
Option
Function
Primary IDE
Controller
Configures the integrated primary IDE controller as either Enabled (default) or Disabled.
Secondary IDE
Controller
Configures the integrated secondary IDE controller as either Enabled (default) or Disabled.
IDE Primary Master
Identifies the first drive attached to the primary IDE interface, usually the boot hard drive. See "
IDE Primary Slave
Identifies the second drive attached to the primary IDE interface, usually a second hard drive. The format of this submenu is the same
as the one described in "
."
IDE Secondary
Master
Identifies the first drive attached to the secondary IDE interface, if there is one. The format of this submenu is the same as the one
described in "
."
IDE Secondary Slave Identifies the first drive attached to the secondary IDE interface, if there is one. The format of this submenu is the same as the one
described in "
."
