Technical Specifications
Dell™ PowerEdge™ 500SC Systems User's Guide
Table A-1. Technical Specifications
Microprocessor
Microprocessor type Intel® Pentium® III microprocessor with a minimum of 1 GHz, an external bus speed of 133 MHz, and a 256 KB level 2 cache
OR
Intel Celeron™ microprocessor at 800 MHz with an external bus speed of 100 MHz and a 128 KB level 2 cache
Front-side bus speed Pentium III: 133 MHz
Celeron: 100 MHz
Internal cache Pentium III: 256 KB Level 2 cache
Celeron: 128 KB Level 2 cache
Expansion Bus
Bus type PCI
Expansion slots Two 64-bit, 33/66-MHz slots
Three 32-bit, 33-MHz slots
Memory
Architecture 72-bit ECC PC-133 SDRAM
Memory module sockets four
Memory module capacities 64, 128, 256, or 512 MB
Minimum RAM 64 MB
Maximum RAM 2 GB
Drives
Diskette drive 3.5-inch, 1.44-MB diskette drive
Tape drive optional internal tape drive
IDE devices three 1-inch, internal, IDE hard drive bays
CD drive one IDE CD drive
Ports and Connectors
Externally accessible:
Serial (DTE) one 9-pin connector; 16550-compatible
Parallel one 25-pin connector (bidirectional)
Video one 15-pin connector
PS/2-style keyboard 6-pin mini-DIN connector
PS/2-compatible mouse 6-pin mini-DIN connector
USB two USB-compliant 4-pin connectors
NIC RJ45 connector for integrated NIC
Video
Video type ATI Rage XL video controller; VGA connector
Video memory 4 MB
Power
DC power supply:
Wattage one 250-W or 330-W power supply
Voltage 90–240 V, 47/63 Hz or 90–265 V, 47/63 Hz
System battery CR2032 3.0-V lithium coin cell
Physical
Height 43.7 cm (17.2 inches)
Width 20.3 cm (8 inches)
Depth 44.5 cm (17.5 inches)
Weight 15.0 kg (33 lb), maximum configuration
Environmental
Temperature:
Operating 10° to 35° C (50° to 95° F)
Storage –40° to 65° C (–40° to 149° F)
