Dell PowerVault ML6000 SMI-S Reference Guide 79
Table 103 Required Blade Instances of FCPort
Table 104 Required Blade Instances of SCSIProtocolController (LUN Mapping Disabled)
When LUN Mapping is disabled, the blade has a SCSIProtocolController representing each zone on the
blade, and since zoning is tied to target ports, this ties the blade SPC object to a blade target port.
Property Blade Instances (one for each blade target FC port)
SystemCreationClassName[key] “CIM_ComputerSystem”
SystemName[key]
CreationClassName[key] “SMIS_FCPort”
DeviceID[key] "B::::WWN”
PortNumber Example: 1
PermanentAddress WW Port Name Format is 16 octets 1234567887654321
ElementName "CIM_FCPort”
OperationalStatus Port Status. Example: ok(2)
NetworkAddress 0
PortType Example: N(10)
ActiveFC4Types SCSI-FCP(8)
OtherNetworkPortType “” since portType is N(10)
LinkTechnology FC(4)
OtherLinkTechnology “”
ActiveCOS 3
UsageRestriction Front-end only(2)
Property
Instances (one for each port on a Fibre Channel I/O
blade)
SystemCreationClassName[key] CIM_ComputerSystem
SystemName[key]
CreationClassName[key] CIM_SCSIProtocolController
DeviceID[key] “B”::.
OtherIdentifyingInfo {blade serial}
Caption “B”::.
Description “FC Blade , port ”
ElementName CIM_SCSIProtocolController
IdentifyingInfoDescriptions {“Serial Number”}
