Dell PowerVault ML6000 SMI-S Reference Guide 67
Table 65 Required Library Instances of SCSIProtocolEndpoint
Table 66 Required Properties of PortImplementsEndpoint
Table 67 Required Library Instances of PortImplementsEndpoint
Table 68 Required Properties of SAPAvailableForElement
Property
Drive Instances (one for each direct-attached
drive)
SystemCreationClassName[key] “CIM_ComputerSystem”
SystemName[key] HID
CreationClassName[key] “CIM_SCSIProtocolEndpoint”
DeviceID[key] ””
ConnectionType Fibre Channel (2)
Role Target (3)
OperationalStatus[valuemap] {Unknown(0)}
ProtocollFType Fibre Channel (56)
Description “SMIS_SCSIProtocolEndpoint”
Property Type Description/Notes
Antecedent REF The LogicalPort.
Dependdent REF The ProtocolEndpoint.
Property
FCPort Instances (one for
each direct-attached FC
drive)
SAS Instances (one for
each SAS drive) SPI Instances (one for
each SCSI drive)
Antecedent CIM_FCPort CIM_SASPort. CIM_SPIPort
Dependent CIM_SCSIProtocolEndpoint CIM_SCSIProtocolEndpoi
nt. CIM_SCSIProtocolEndpoi
nt
Property Type Description/Notes
AvailableSAP REF The ServiceAccessPoint.
ManagedElement REF The ManagedElement that is accessible by the SAP.
