Power Supply
The 145-W power supply can operate from an AC power source of 115 VAC at 60 Hz or 230 VAC at 50 Hz. The power supply provides the DC operating
voltages and currents listed in the following table.
DC Power Connectors
Power Supply DC Connector Pin Assignments
Output Voltage 1 Regulation Minimum Current (A) Maximum Current (A) 2
+12 VDC +/–5% 0.0 4.5
+5 VDC +/–5% 1.0 16.0
+3.3 VDC +/–5% 0.1/0.0 3 10.0
– 5 VDC +/–10% 0.0 0.3
– 12 VDC +/–10% 0.0 0.3
+5 VFP +/–5% 0.0 1.2
1 Outputs meet and do not exceed SELV requirements per electrical standards (UL 1950, IEC 950, or EN60950 Par. 2.3).
2 Maximum continuous combined load on +5 VDC and +3.3 VDC outputs do not exceed 85 W.
3 In system configurations where +3.3 VDC is not used, all other outputs stay within regulation while the +3.3 VDC output is in a zero load condition.
