Dell Dimension 2200 - Manual (Page 37)

Back to Contents Page
Technical Specifications
Dell™ Dimension™ 2200
Microprocessor Video
System Information Audio
Expansion Bus Controls and Lights
Memory Power
Drives Physical
Ports and Connectors Environmental
Microprocessor
Microprocessor type Intel® Celeron® microprocessor that runs at 1.20,
1.30, or 1.40 GHz internally and 100 MHz externally
NOTE: Microprocessor offerings vary by country.
L1 cache 32 KB (16-KB data cache; 16-KB instruction cache)
L2 cache 256-KB SRAM that resides in the processor's core.
The L2 cache runs at the processor's internal clock
speed.
System Information
System chip set Intel 810E
DMA channels two
Interrupt levels 24 APIC mode
System BIOS chip 4 Mb (512 KB)
System clock speed 100 MHz
Expansion Bus
Bus types PCI (version 2.2)
Bus speed PCI: 33 MHz
PCI connectors supports four three-quarter–length cards
PCI connector size 120 pins
PCI connector data width
(maximum) 32 bits
Memory
Architecture non-ECC SDRAM modules
Memory connectors two; gold contacts
Memory capacities 128, 256, and 512 MB (non-ECC)
Minimum memory 128 MB (non-ECC)
Maximum memory 512 MB (non-ECC)
Frequency 100 MHz
Voltage 3.3 V
Data bus width 64 bits
Drives
Externally accessible one 5.25-inch bay
two 3.5-inch bays
Internally accessible one bay for 1-inch–high IDE hard drive
Available devices ATA-66 Ultra DMA hard drive, CD drive, DVD drive, and
CD-RW drive
Ports and Connectors
Externally accessible:
Serial 9-pin connector; 16550C-compatible
Parallel 25-hole connector (bidirectional)
Video 15-hole connector
Keyboard 6-pin mini-DIN connector or USB connector
