Advanced Troubleshooting: Dell XPS 700 Service Manual
adtshoot.htm[4/11/2014 11:32:16 AM]
NOTE:
The Quickboot feature changes the boot sequence for the current boot only. Upon restart, the computer
boots according to the boot sequence specified in system setup.
7. At the CD-ROM Startup Menu, use the up- and down-arrow keys or press the appropriate number on the keyboard to
highlight Boot from CD-ROM, and then press
If you wait too long and the Windows logo appears, continue to wait until you see the Windows desktop, then shut down
your computer and try again.
8. Press <1> to select the Dell Diagnostics.
9. At the Dell Diagnostics Menu press <1> to select the Dell Diagnostics for ResourceCD (graphical user interface).
10. At the Dell Diagnostics Main Menu, left-click with the mouse, or press
).
NOTE:
Write down any error codes and problem descriptions exactly as they appear and follow the instructions on
the screen.
11. After all tests have completed, close the test window to return to the Dell Diagnostics Main Menu.
12. Remove the Drivers and Utilities CD, then close the Main Menu window to exit the Dell Diagnostics and restart the
computer.
Dell Diagnostics Main Menu
The following tests can be run from the Dell Diagnostics Main Menu:
Option
Function
Express
Test
Performs a quick test of system devices. The test typically takes 10 to 20 minutes and requires no interaction on
your part. Run Express Test first to increase the possibility of tracing the problem quickly.
Extended
Test
Performs a thorough check of system devices. The test typically takes an hour or more and peridocially requires
your input to answer specific questions.
Custom
Test
Tests a specific device in the system and can be used to customize the tests you want to run.
Symptom
Tree
Lists a number of common symptoms and allows you to select a test based on the symptom of the problem you
are having.
For any problem encountered during a test, a message appears with an error code and a description of the problem. Write
down the error code and problem description exactly as it appears and follow the instructions on the screen. If you cannot
resolve the problem, contact Dell (see "Contacting Dell" in your Owner's Manual).
NOTE:
The Service Tag for your computer is located at the top of each test screen. When contacting Dell support, have
your Service Tag ready.
The following tabs provide additional information for tests run from the Custom Test or Symptom Tree option:
Tab
Function
Results
Displays the results of the test and any error conditions encountered.
Errors
Displays error conditions encountered, error codes, and the problem description.
