Ultra-Wide Band (UWB)/Latitude ON Flash Card
Dell Latitude E4310 Service Manual
Removing the UWB/Latitude ON Flash Card
1. Follow the procedures in Before Working Inside Your Computer .
2. Remove the battery .
3. Remove the LED covers .
4. Remove the keyboard .
5. If you are removing an UWB card, disconnect the cable from the UWB card.
6. Remove the screw that secures the UWB/Latitude ON Flash card to the computer.
7. Remove the UWB/Latitude ON Flash card from the computer.
Replacing the UWB/Latitude ON Flash Card
To replace the UWB/Latitude ON Flash card, perform the above steps in reverse order.
Back to Contents Page
WARNING: Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
NOTE: You may need to install Adobe Flash Player from Adobe.com in order to view the illustrations below.
