LED Covers
Dell Latitude E4310 Service Manual
Removing the LED Covers
1. Follow the procedures in Before Working Inside Your Computer .
2. Remove the battery .
3. Using a plastic scribe, gently pry the edges of the right LED cover.
4. Lift the right LED cover up and away from the computer.
5. Using a plastic scribe, gently pry the edges of the left LED cover.
6. Lift the left LED cover up and away from the computer.
Replacing the LED Covers
To replace the LED covers, perform the above steps in reverse order.
Back to Contents Page
WARNING: Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
NOTE: You may need to install Adobe Flash Player from Adobe.com in order to view the illustrations below.
