Replacing the hinge cover – Dell Vostro 1310 (Early 2008) User Manual
Page 32
Replacing the Hinge Cover
1.
Align the two tabs underneath the left edge of the hinge cover with the corresponding notches in the computer.
2.
Moving from left to right, press down until the hinge cover snaps into place.
Back to Contents Page
CAUTION:
Before you begin any of the procedures in this section, follow the safety instructions that shipped with your computer.
NOTICE:
The hinge cover is fragile and can be damaged if extreme force is used. Exercise care when replacing the hinge cover.
NOTE:
This procedure assumes that you have completed the removal procedure first.
