4. Replace the display assembly (see Replacing the Display Assembly ).
5. Replace the keyboard (see Replacing the Keyboard ).
6. Replace the hinge cover (see Replacing the Hinge Cover ).
7. Replace the WLAN card (see Replacing a WLAN Card ).
8. Replace the hard drive (see Replacing the Hard Drive ).
Display Panel
Removing the Display Panel
1. Follow the instructions in Before Working on Your Computer .
2. Remove the hard drive (see Removing the Hard Drive ).
3. Remove the WLAN card (see Removing a WLAN Card ).
4. Remove the hinge cover (see Removing the Hinge Cover ).
5. Remove the keyboard (see Removing the Keyboard ).
6. Remove the display assembly (see Removing the Display Assembly ).
7. Remove the display bezel (see Removing the Display Bezel ).
8. Remove the display inverter (see Removing the Display Inverter ).
9. Remove the two M2 x 5-mm screws from the display hinges.
10. Remove the camera/microphone assembly (see Removing the Camera and Microphone Assembly ).
11. Lift the display panel assembly out of the top cover.
12. Remove the six M2 x 3-mm screws (three on each side of the display panel) from the display hinge panels.
Replacing the Display Panel
CAUTION: Before you begin the following procedure, follow the safety instructions that shipped with your computer.
1 M2 x 5-mm screws (2) (on display hinges) 2 display panel
3 M2 x 3-mm screws (6) (on display hinge panels) 4 top cover
