take 10 to 20 minutes
Extended Test Performs a thorough check of devices in the system. This typically
can take an hour or more.
Custom Test Use to test a specific device or customize the tests to be run.
Symptom Tree This option allows you to select tests based on a symptom of the
problem you are having. This option lists the most common
symptoms.
3. If a problem is encountered during a test, a message appears with an error code and a description of the problem.
Write down the error code and problem description and contact Dell.
NOTE: The Service Tag for your computer is located on the bottom of your system. When you
contact Dell, technical support will ask for your Service Tag.
4. If you run a test from the Custom Test or Symptom Tree option, click the applicable tab described in the
following table for more information.
Tab Function
Results Displays the results of the test and any error conditions
encountered
Errors Displays error conditions encountered, error codes, and the
problem description.
Help Describes the test and may indicate requirements for running the
test.
Configuration Displays your hardware configuration for the selected device.
The Dell Diagnostics obtains configuration information for all
devices from the system setup program, memory, and various
internal tests, and it displays the information in the device list in
the left pane of the screen. The device list may not display the
names of all the components installed on your computer or all
devices attached to your computer.
Parameters Allows you to customize the test by changing the test settings.
5. When the tests are completed, close the test screen to return to the Main Menu screen. To exit the Dell
Diagnostics and restart the computer, close the Main Menu screen.
6. Remove the Dell Drivers and Utilities CD (if applicable).
