Removing and Replacing Parts 4-13
6\VWHP %RDUG $VVHPEO\ FRQWLQXHG
System board assembly
with system board and
processor module ASSY,PRM/PWA,ENGINE,
CPi
xxx *
System-board engine
subassembly SUBASSY,PWA/ENGINE,CP
I/R board PWA,FAST IR,CP
Microphone boot GRMT,RBR,BOOT,MCPHN
Main system board PWA,PLN,0M,NB,CP
Video/PC Card
board PWA,DTRBD,VID/PCMCIA,CP
LED board PWA,LED,CP
Lower EMI shield SHLD,BTM,PLN ASSY,CP
Upper EMI shield,
1st SHLD,TOP,1ST,PLN ASSY,CP
Upper EMI shield,
2nd SHLD,TOP,2ND,PLN ASSY,CP
Exhaust fan and
cable FAN,25X25X10,CP
Microphone MCPHN,CP
Reserve battery BTRY,RSRV,7.2,30MAH,6,NIHD
Foam pad PAD,FOAM,BTRY,RSRV,CP
7KHUPDO &RROLQJ $VVHPEO\
Service kit, thermal cooling
subassembly SVC,SUBASSY,HTSNK,
CPU,HYB,CP 4-30
7RXFK 3DG
Touch-pad service kit SVC,TPAD,SQ,INTFC,CP 4-13
Touch-pad subassembly TPA,INTFC,CP
* Substitute the drive capacity for xxxxx, the drive height for yy, and the
manufacturer for zzz.
7DEOH 3DUWV DQG $VVHPEOLHV FRQWLQXHG
3DUW RU $VVHPEO\ 1DPH 2UGHU 1DPH )LJXUH
