4-12 Dell Latitude CP and CPi Service Manual
6FUHZV
LCD panel SCR,M3X5,PHH,LP,ZPS 4-18,
4-19
LCD hinge SCR,M3X5,PHH,LP,ZPS 4-16
LCD inverter board SCR,M3X5,PHH,LP,ZPS 4-21
LCD bezel and latch,
12.1-inch display SCR,M3X5,PHH,LP,ZPS 4-17
Keyboard SCR,M2.6X12,PHH,LP,ZPS 4-9
Thermal cooling assembly SCR,M2X2.5,PHH,LP,ZPS 4-30
Touch-pad SCR,M2.6X1.8,PHH,XLP,ZPS 4-13
Palmrest, front edge SCR,M2.6X12,PHH,LP,ZPS 4-12
Palmrest, hard-disk drive
area SCR,M2.6X5,PHH,LP,ZPS 4-12
I/R board SCR,M2.6X5,PHH,LP,ZPS 4-32
Upper EMI shield, 1st SCR,M2.6X5,PHH,LP,ZPS -
PC/Video board SCR,M2.6X5,PHH,LP,ZPS -
Back cover SCR,M2.6X5,PHH,LP,ZPS 4-11
Audio board SCR,M2.6X5,PHH,LP,ZPS 4-26
Upper EMI shield, 2nd SCR,M2.6X5,PHH,LP,ZPS
Bottom-case bracket SCR,M2.6X5,PHH,LP,ZPS 4-27
Exhaust fan SCR,M2.6X12,PHH,LP,ZPS 4-31
6SHDNHUV
Left speaker assembly SUBASSY,SPKR,LF,W/WIRES
Right speaker assembly SUBASSY,SPKR,RT,W/WIRES
6\VWHP %RDUG $VVHPEO\
System board assembly,
CP
xxx,service kit *
SVC,ASSY,PRM/
PWA,ENGINE,CP
xxx *
4-30
System board assembly,
CPi
xxx,service kit *
SVC,ASSY,PRM/
PWA,ENGINE,CPi
xxx *
Service tag install disk DISK,FLD SERV,F3,US,LXP
System board assembly
with system board and
processor module ASSY,PRM/PWA,ENGINE,
CP
xxx *
* Substitute the drive capacity for xxxxx, the drive height for yy, and the
manufacturer for zzz.
7DEOH 3DUWV DQG $VVHPEOLHV FRQWLQXHG
3DUW RU $VVHPEO\ 1DPH 2UGHU 1DPH )LJXUH
