8. Remove the device from the media bay:
a. Close the display and turn the computer upside-down.
b. Slide and hold the latch release away from the media bay device.
c. Pull the device out of the media bay.
Screw Counts and Locations
You may find it helpful to print the following table to use for keeping the screws organized as you disassemble the computer. The table lists the components from right
to left in the order that they are to be removed from the computer.
NOTICE: Only a certified service technician should perform repairs on your computer. Damage or inoperability due to
servicing not authorized by Dell is not covered by your warranty.
Hard-Disk Drive
1
Memory
2
Modem
2
Hinge Covers
2
(piece across top of keyboard)
Keyboard
2 (from top)
Thermal Shield
4 (silver) for Inspiron 5000
5 (silver) for Inspiron 5000e
(Remove the diskette-drive-cable retaining
bracket before removing the thermal shield.)
