Dell Latitude E5430 (Mid 2012) - Manual (Page 73)

Option Description
USB Wake Support Allows you to enable USB devices to wake the system from Standby.
NOTE: This feature is only functional when the AC power adapter is
connected. If the AC power adapter is removed during Standby, the
system setup will remove power from all of the USB ports to
conserve battery power.
• Enable USB Wake Support
• Default Setting: Enable USB Wake Support is not selected
Wireless Radio Control Allows you to enable or disable the feature that automatically switches
from wired or wireless networks without depending on the physical
connection.
• Control WLAN Radio
• Control WWAN Radio
• Default Setting: Control WLAN radio or Control WWAN radio is not
selected
Wake on LAN/WLAN Allows you to enable or disable the feature that powers on the computer
from the Off state when triggered by a LAN signal.
• Disabled: This option is enabled by default
• LAN Only
• WLAN Only
• LAN or WLAN
Block Sleep This option lets you block entering to sleep (S3 state) in Operating
System environment.
Block Sleep (S3 state) - This option is disabled by default. POST
Primary Battery
Configuration Allows you to select the charging mode for the battery. The options are:
• Standard Charge
• Express Charge
• Predominately AC use
• Auto Charge: This option is enabled by default.
• Custom Charge
If Custom Charge is selected, you can also configure Custom Charge
Start and Custom Charge Stop.
NOTE: All charging modes may not be available for all the batteries.
Battery Slice Configuration Allows you to select the type of charge for the battery. The options are:
• Standard Charge
• Express Charge : This option is enabled by default.
NOTE: Express charge may not be available for all the batteries.
73
