Text mode
Original mode

Flex a stack of envelopes back and forth and then straighten the edges on a level surface. Press down
the corners to flatten them.

Fan the envelopes. This prevents the edges of the envelopes from sticking together and helps them
feed properly.

NOTE:

When you load envelopes, do not exceed the maximum stack height of 64.7 mm (2.55 in.).

The envelope feeder holds a maximum of 85 envelopes (75 g/m

, 20 lb bond).

Load the stack of envelopes flap side down with the stamp area and the flap on the left. The end of the
envelopes with the stamp area enters the envelope feeder first. Let the envelopes at the bottom of the
stack slide into the envelope feeder slightly more than the ones at the top of the stack.

NOTICE:

Never use envelopes with stamps, clasps, snaps, windows, coated linings, or self-stick

adhesives. These envelopes may severely damage the printer. See

Envelopes

for more information.
