84

Appendix

www

.dell.com | support.dell.com

Controls and Lights
Power control

push button

Power light

green

Hard-drive access light

green

Diagnostic code lights

four bicolor (amber and green) located on

back panel

Power
DC power supply:

Wattage

145 W

Heat dissipation

495 BTU (fully loaded computer without

monitor)

Voltage (switch-selectable

on back panel)

90 to 135 V at 60 Hz; 180 to 265 V at 50 Hz;

100 V at 50 to 60 Hz for Japanese computers

Backup battery

3-V CR2032 coin cell

Physical
Height x Width x Depth

39 x 16.8 x 34 cm

(15.375 x 6.625 x 13.375 inches)

Weight

9.9 Kg (22 lbs)

Environmental
Temperature:

Operating

10° to 35°C (50° to 95°F)

3

Storage

–40° to 65°C (–40° to 149°F)

3

At 35°C (95°F), the maximum operating altitude is 914 m (3000 ft).
