22
Current Monitoring
BMC supports current sensor as shown in Table 1-11. The current sensor
monitoring aims to gain the SLED power consumption for power
management used.
FAN Control and Monitoring
The BMC receives all fan tachometers of the threshold base from the chassis
controller. The following is the table of the fan speed thresholds.
Table 1-11. Current Monitoring
Current Sensor Number UNCT UCT
SLED 12V 0x4E 216 252
Table 1-12. Fan Thresholds
Fan Sensor Sensor
Number
LCT LNCT
SYS FAN 1 0x68 600 rpm 720 rpm
SYS FAN 2 0x69 600 rpm 720 rpm
SYS FAN 3 0x6A 600 rpm 720 rpm
SYS FAN 4 0x6B 600 rpm 720 rpm
SYS FAN 5 0x6C 600 rpm 720 rpm
SYS FAN 6 0x6D 600 rpm 720 rpm
SYS FAN 7 0x6E 600 rpm 720 rpm
SYS FAN 8 0x6F 600 rpm 720 rpm
