21
Temperature Monitoring
The system supports the following temperature sensors.
Hide Thresholds Button Clicking Hide Thresholds button reduces the sensor
reading table and hides the various threshold settings for
every sensor.
Table 1-9. Temperature Sensors (8-Sled Chassis)
Temperature Sensor Number UNCT UCT
CPU Temp 0x44 77 82
Ambient Temp 0x40 44 47
DIMM Temp 0x4C 68 72
Rear Temp 1 0x54 46 47
Rear Temp 2 0x55 46 47
Rear Temp 3 0x56 46 47
Table 1-10. Temperature Sensors (12-Sled Chassis)
Temperature Sensor Number UNCT UCT
CPU Temp 0x44 71 76
Ambient Temp 0x40 44 47
DIMM Temp 0x4C 68 72
Rear Temp 1 0x54 46 47
Rear Temp 2 0x55 46 47
Rear Temp 3 0x56 46 47
Table 1-8. Sensor Readings With Thresholds
Item Description
