Dell PowerEdge C5220 User Manual
Page 14

14
Table 1-5. Blinking Fault LED Conditions
ID LED
Blue
Off
Normal status (by IPMI
Chassis Identify
command or System ID
Button)
Turn off the ID LED.
1. ipmitool raw 0x00 0x04
0x00
2. ipmitool raw 0x00 0x04
0x00 0x00
Solid On Identify the system
Turn on the ID LED.
1.ipmitool raw 0x00 0x04 0x3c
01
Blinking Identify the system with
interval
1. IPMI chassis identify
command without request
data ipmitool raw 0x00 0x04
2. IPMI chassis identify
command with only 1
parameter data ipmitool raw
0x00 0x04 0x3c (blink 60 sec)
3. IPMI chassis identify
command with 2 parameter
data ipmitool raw 0x00 0x04
0x3c 0x00 (blink 60 sec)
Heartbeat
LED
Green Off
BMC is not ready
Blinking BMC is ready
Index
Sensor Name
Event Triggers
1
CPU Temp
• Upper Critical Going High
• Upper Non-Critical Going High
Ambient Temp,
DIMM Temp
Rear Temp 1
Rear Temp 2
Rear Temp 3
2
SLED 12V
• Upper Critical Going High
• Upper Non-Critical Going High
Table 1-4. LED Status
LED
Color Status
Occurrence
Note
