Dell Latitude E6520 (Early 2011) - Manual (Page 95)

Ports and Connectors
Audio one microphone connector/stereo
headphone/speakers connector
Video
• one 15-pin VGA connector
• one 19-pin HDMI connector
Network adapter one RJ-45 connector
USB three 4-pin USB 2.0-compliant connectors and
one eSATA/USB 2.0-compliant connector
Memory card reader one 5-in-1 memory card reader
IEEE 1394: one 4-pin connector
Contactless Smart Card
Supported Smart Cards/Technologies ISO14443A — 106 kbps, 212 kbps, 424 kbps,
and 848 kbps ISO14443B — 106 kbps, 212
kbps, 424 kbps, and 848 kbps ISO15693 HID
iClass FIPS201 NXP Desfire
Display
Type WLED display
Size 15.6 inch high definition (HD)
Dimensions:
Height 210.00 mm (8.26 inches)
Width 360.00 mm (14.17 inches)
Diagonal 396.24 mm (15.60 inches)
Active area (X/Y) 344.23 mm x 193.54 mm
Maximum resolution 1366 x 768 pixels at 262K colors
Maximum Brightness 220 nits
Operating angle 0° (closed) to 135°
Refresh rate 60 Hz
Minimum Viewing angles:
95
