Technical Overview 9
1 12 V power connector (PWR2) 2 processor socket
3 processor fan connector
(CPU_FAN)
4 memory module connector
(DIMM1)
5 memory module connector
(DIMM2)
6 main power connector (PWR1)
7 SATA connector (SATA_3) 8 SATA connector (SATA_1)
9 media card reader connector
(F_USB2)
10 front panel USB connector
(F_USB1)
11 USB power connector
(USB_PWR1)
12 power switch module connector
(FP1)
13 front panel audio (F_AUDIO) 14 PCI card slot (PCI2)
15 battery socket (BAT) 16 PCI-Express x16 card slot
(PCI-E1_16X)
17 CMOS reset jumper
(CLR_CMOS)
