11 Run the ISP cable through the controller board shield.
12 Open the shield using the blue handle.
2
1
13 Attach the blue plug of the ISP solution interface cable into the blue receptacle on the controller board.
Note: If you have installed a printer hard disk, then you need to remove it. For more information, see
“Removing a printer hard disk” on page 41 . To reinstall the printer hard disk, see “Installing a printer hard
disk” on page 39 .
Additional printer setup 37
