Camera Module
57
12
Camera Module
WARNING:
Before working inside your computer, read the safety information
that shipped with your computer. For additional safety best practices information,
see the Regulatory Compliance Homepage at
www.dell.com/regulatory_compliance.
CAUTION:
Only a certified service technician should perform repairs on your
computer. Damage due to servicing that is not authorized by Dell is not covered by
your warranty.
CAUTION:
To avoid electrostatic discharge, ground yourself by using a wrist
grounding strap or by periodically touching an unpainted metal surface (such as a
connector on your computer).
CAUTION:
To help prevent damage to the system board, remove the main battery
(see "Removing the Battery" on page 15) before working inside the computer.
Removing the Camera Module
1 Follow the instructions in "Before You Begin" on page 9.
2 Remove the battery (see "Removing the Battery" on page 15).
3 Follow the instructions from step 3 to step 9 in "Removing the Palm-Rest
4 Remove the display assembly (see "Removing the Display Assembly" on
5 Remove the display bezel (see "Removing the Display Bezel" on page 44).
6 Remove the display panel (see "Removing the Display Panel" on page 46).
7 Gently peel the camera module from the from the display back cover.
8 Remove the camera module.
