48 Display
6 Align the screw holes on the display panel with the screw holes on the
display back cover and replace the eight screws.
7 Replace the display bezel (see "Replacing the Display Bezel" on page 45).
8 Replace the display assembly (see "Replacing the Display Assembly" on
page 43).
CAUTION: Before turning on the computer, replace all screws and ensure that no
stray screws remain inside the computer. Failure to do so may result in damage to
the computer.
Display Cable
Removing the Display Cable
1 Follow the instructions in "Before You Begin" on page 9.
2 Remove the display assembly (see "Removing the Display Assembly" on
page 41).
3 Remove the display bezel (see "Removing the Display Bezel" on page 44).
4 Remove the display panel (see "Removing the Display Panel" on page 46).
5 Lift the tape that secures the display cable to the display-board connector
and disconnect the display cable.
