Crestron electronic TPMC-8T - Manual (Page 22)

Isys i/O™ 8.4” TableTop WiFi Touchpanel Crestron TPMC-8T
Audio
The Audio button opens the “Audio Setup” window. Overall All Audio volume and
balance controls and a Mute checkbox are available as well as volume and balance
controls and Mute checkboxes for Wave Out and Microphone In. The Microphone In
settings also include a Boost checkbox, which applies a 20 dB boost to the level of
the microphone input. The key click sound can be enabled or disabled with the Key
Click On and Off radio buttons.
NOTE: The Audio Output section of the “Audio Setup” window is not applicable to
the TPMC-8T and is not used.
Touching Play Test plays a short internal audio file. Changes to audio settings are
made in real time.
“Audio Setup” Window
18 • Isys i/O™ 8.4” TableTop WiFi Touchpanel: TPMC-8T Operations Guide – DOC. 6567C
