Dell Latitude E6530 (Mid 2012) - Manual (Page 52)

6. Remove the display panel from the display assembly.
Installing the Display Panel
1. Connect the LVDS cable and stick the LVDS cable connector tape.
2. Flip the display and place it in the display assembly.
3. Tighten the screws to secure the display panel to the display assembly.
4. Install:
a) display bezel
b) display assembly
c) battery
5. Follow the procedures in After Working Inside Your Computer .
Removing the Display Assembly
1. Follow the procedures in Before Working On Your Computer .
2. Remove:
a) battery
b) base cover
3. Remove the screws that secure the LVDS support bracket to the system board.
52
