Dell Latitude E6530 (Mid 2012) - Manual (Page 27)

6. Disconnect the bluetooth cable from the bluetooth card.
Installing the Bluetooth Card
1. Connect the bluetooth cable to the bluetooth card.
2. Connect the other end of the bluetooth cable to the system board.
3. Place the bluetooth card in its location in the computer.
4. Tighten the screw to secure the bluetooth card to the system board.
5. Install:
a) base cover
b) battery
6. Follow the procedures in After Working Inside Your Computer .
Removing the Modem Card
1. Follow the procedures in Before Working Inside Your Computer .
2. Remove the:
a) battery
b) base cover
3. Remove the screw that secures the modem card to the computer.
27
