Removing and Replacing Parts 4-37
0RGHP&DUG
The modem card is an option available only to customers in the U.S. and
Canada.
The modem card can be removed without removing the palmrest. To remove
the modem card, see Figure 4-16 and follow these steps:
1. Remove the keyboard.
2. Remove the 14-mm screw from the right side of the modem card.
3. Pry up the modem card from the right side.
4. Disconnect the modem cable from connector J2 on the modem card.
5. Remove the modem card.
When installing the modem card, slip it into place under the system-board
retaining clip. Put pressure only on the areas where the connectors on the
modem card and on the video board fit together. Pressing on other areas may
flex the card and break connections.
7\SH RI 6FUHZ 7RUTXH
FPH 2.5 x 14 (1) 3.0–3.5 kgf-cm
