Removing and Replacing Parts 4-19
,QYHUWHUIRU,QFK'LVSOD\$VVHPEO\
&$87,21 7KH IROORZLQJ SURFHGXUH VKRXOG EH SHUIRUPHG RQO\ E\
GHSRW UHSDLU WHFKQLFLDQV
To remove the inverter, see Figure 4-13 and follow these steps:
1. Remove the display assembly.
2. Remove the bezel.
3. Disconnect the inverter signal cable from the side-lift ZIF connector CN1 on
the left side of the inverter by gently pulling each side of the ZIF connector,
and then pulling out the cable.
4. Disconnect the LED cable from connector CN3 on the inverter.
5. Disconnect the LCD cable from connector CN2 on the inverter. (A red dot
denotes the top of the LCD cable connector when you are installing the
cable.)
6. Remove the inverter.
