Replacing the Keyboard



1.

Reconnect the keyboard to the system board connector.



2.

Slide the bottom of the keyboard into the computer base.



3.

Replace the two M2.5 x 5-mm screws across the top of the keyboard.



4.

Replace the

hinge cover

.

Back to Contents Page



NOTICE:

To avoid scratching the palm rest when replacing the keyboard, hook the five tabs along the front edge of the keyboard into the palm rest,

and then secure the keyboard into place. Also, be sure the display panel is lying flat (180 degrees) against the working surface to avoid scratching the
display panel.

NOTE:

You may need to push the bottom of the keyboard down slightly to seat the keyboard into the computer base.
